Fotocontrol térmico con conexión directa JL-126 para el control de la bomba de drenaje de la piscina
Profesional Fabricante de fotocélulas Aquí ahora.
OEM y ODM Servicio integral Personalizado, Le enviaremos una muestra para confirmar la calidad.
Usage scenario: Used to control the drainage pump of a private swimming pool
Características
Time Delay 30~120s
Ambient Temperature： -40℃ ~ +70℃
Additional Swivel Available
Screw Thread （NPT 1/2″）& Zinc Alloy Nut
Aluminum Die-cast Enclosure
Heavy Duty up to 3000VA
Descripción del Producto
Dusk to Dawn Light Sensor Parameter
N.º de modelo
JL-126A
JL-126B
JL-126D
Voltaje nominal
120VAC
220-240 VCA
277VAC
Frecuencia nominal
50/60 Hz
Carga nominal
3000W Tungsten, 3000VA Ballast
Consumo de energía
1.5W MAX
On/Off Level
10-20 Lx On 30-60 Lx Off
Ambient Temp.
-40℃ to +70℃
Humedad relacionada
96%
Body Meas
50(wide)x37(depth)x91(height)mm
Swivel Meas
85(L)x36(Dia.Max)mm;200°
Weight Approx.
60 grs
Time of warranty
Each one uses up to 5000 times,3 Years Warranty!
For high-end users:
The aluminum die cast casing and military grade nickel chromium alloy sensor ensure that your pool pump is worry free for ten years in salt spray and chlorine environments, reducing maintenance times by 90% compared to plastic controllers
For engineering contractors:
The combination of zinc alloy nuts and nickel plated threads reduces installation costs and avoids after-sales replacement time caused by corrosion
Spanish
English
Russian
Arabic
Italian
Profesional Fabricante de fotocélulas Aquí ahora.
OEM y ODM Servicio integral Personalizado, Le enviaremos una muestra para confirmar la calidad.
Usage scenario: Used to control the drainage pump of a private swimming pool
Características
Descripción del Producto
Dusk to Dawn Light Sensor Parameter
30-60 Lx Off
For high-end users:
The aluminum die cast casing and military grade nickel chromium alloy sensor ensure that your pool pump is worry free for ten years in salt spray and chlorine environments, reducing maintenance times by 90% compared to plastic controllers
For engineering contractors:
The combination of zinc alloy nuts and nickel plated threads reduces installation costs and avoids after-sales replacement time caused by corrosion
Especificación del sensor de fotocélula
