| Model | Base Dia(mm) | Pins Dia(mm) | Match Cover
Material(Dia*H) mm |
Cover Material | Base Material | Pins Material | interface Standard |
| JL-701J | 43.5 | 12 | 20/35 | PC | PBT | Brass Tinned | Zhaga Book18 |
| JL-711J | 43.5 | 25 | 25/35 | PC | PBT | Brass Tinned | Zhaga Book18 |
| JL-731J | 63.2 | 25 | 50 | PC | PBT | Brass Tinned | Zhaga Book18 |
| JL-732J | 63.2 | 12 | 50 | PC | PBT | Brass Tinned | Zhaga Book18 |
| JL-741J | 75.3 | 12 | 35/50 | PC | PBT | Brass Tinned | Zhaga Book18 |
| JL-742J | 75.3 | 25 | 35/50 | PC | PBT | Brass Tinned | Zhaga Book18 |
| Note: Scalable solution allows use of Ø40mm photocell and a Ø80mm central management system with the same connection interface |
| Note:In this project case, the combination of zhaga socket and protect cover/ shorting cap can be equivalent to the pre-installation project of NEMA standard smart street light.Retrofit and upgrade traditional street lights.Compared with the street lamp project of the NEMA socket, the zhaga socket has a more beautiful design and saves costs. |
| Note: We provide different sizes of zhaga light control covers and bases for you to design your own controller. |
| Note: This zhaga light control has the same function as the traditional nema street light controller. It controls the switch of the street light through the brightness of the ambient light and reduces the cost. |
| Note: This zhaga product design is mainly applied to the principle of infrared micro- wave induction. Through infrared induction of moving objects (cars or people in motion), street light switches are controlled, which not only satisfies lighting needs but also saves electricity costs. |
| Note: This series of light controller products are based on the ZHAGA BOOK18 inter- face standard development of smart Hui type rotary lock light controller, adopts light sensor + microwave mobile combined sensor, can output DALI Dimming signal. The light controller is suitable for roads, lawns, courtyards, parks, parking lots, industrial Lighting scenes such as mines. |
| Note:In this project case combination, choose the zhaga socket to match the zhaga series finished light control. According to the needs of the actual project, choose the nature of the controller (light control, smart or infrared control) to choose the right product. Compared with light control and intelligent control, infrared control is generally suitable for indoors, such as large factories and underground garages. Or it can be combined with intelligent light control to realize the intelligentization of urban lighting. |
| Note:The zhaga series of light control products are suitable for roads, lawns, court- yards, parks and other scenes. When the zhaga series products with microwave ind- uction are used more widely, in addition to outdoor lighting areas, including indoor factory areas, garages, offices, corridors and other areas. . Compared with nema standard controllers, zhaga will be combined with smart homes in the future with its compact size and microwave induction function. |
